2x CV Joint Drive Shaft Set for Toyota Hilux GGN125 GUN125 GUN126 4WD

PRODUCT OVERVIEW

This is a pair of front CV joint drive shafts designed as aftermarket replacement axles for selected Toyota Hilux GGN125, GUN125, GUN125R, GUN126 and GUN126R 4WD models from 10/2015 onwards.

KEY FEATURES

• Complete axle shaft assemblies with CV joints and boots
• Supplied as a matched pair for front left (LH) and right (RH) sides
• Pre-assembled for straightforward installation
• Brand new aftermarket replacement components

VEHICLE APPLICATION

Suitable for the following Toyota Hilux 4WD variants:

• Hilux GUN125 / GUN125R, 2.4L 2GD-FTV 4WD, approx. 10/2015 – 04/2022
• Hilux GUN126 / GUN126R, 2.8L 1GD-FTV 4WD, approx. 10/2015 – current

Always confirm compatibility with your vehicle details before purchase.

SPECIFICATIONS

• Configuration: Constant velocity joint complete shaft set, pre-assembled
• Length (compressed): 630.0 mm
• Drive shaft seal diameter (wheel end): 72.5 mm
• Drive shaft seal diameter (inner): 47.0 mm
• Spline count (wheel end): 30T
• Spline count (diff side): 30T

PACKAGE CONTENTS

• 2 × CV joint drive shafts (front LH and RH)

INSTALLATION NOTES

• Professional installation is highly recommended
• Check all dimensions, spline counts and seal diameters before fitting
• Inspect and torque all fasteners to the vehicle manufacturer’s specifications
