Front Lower Control Arm Pair with Ball Joints for Toyota Hilux & Fortuner 4WD

PRODUCT OVERVIEW

Brand new front lower left and right control arm pair for 4WD applications, supplied complete with pre-fitted ball joints and rubber bushes.

Note: Does not fit Toyota Hilux GUN126 Rogue, Rugged, GR-Sport or SR5 "Wide Track" sub-models.

KEY FEATURES

• Supplied as a matched left and right front lower control arm pair
• Includes pre-installed ball joints
• Includes rubber bushes (Taiwan rubber)
• Designed for 4WD suspension applications

VEHICLE COMPATIBILITY

• Toyota Hilux GUN126 / GUN126R 2.8L 1GD-FTV (10/2015-on) 4WD – SR5, SR5+, SR, SR5 Cruiser, SR Extra Cab (excluding Rogue, Rugged, GR-Sport & SR5 Wide Track)
• Toyota Hilux GUN125 / GUN125R 2.4L 2GD-FTV (10/2015-on) 4WD – models including Workmate, X, Z
• Toyota Fortuner GUN156 / GUN156R 2.8L 1GD-FTV (11/2015-on) 4WD – models including GXL, Crusade, Limited, GX, GX Nav

SPECIFICATIONS

• Configuration: Front lower control arms, left and right
• Ball joint cone: 17 mm
• Thread size: M16 x 1.5
• Length (outside of bush to bush): 448 mm
• Mount type: With ball joint and rubber mounts

WHAT'S INCLUDED

• 2 x Front lower control arms (left and right) with ball joints and bushes pre-installed

WARRANTY

• 12 month / 20,000 km warranty (whichever occurs first)
