4 Spool P40 Hydraulic Directional Control Valve 40L/min, 200 Bar

PRODUCT OVERVIEW

4 spool P40 hydraulic directional control valve designed for a wide range of mobile hydraulic applications, including tractors, loaders, excavators, forklifts, trailers, trenchers, vertical mast lifts and wood chippers. Compact monoblock construction delivers reliable performance in demanding environments.

KEY FEATURES

• 4-bank double-acting monoblock lever valve (spring-centered levers)
• Integrated adjustable relief valve to set system working pressure
• Parallel circuit with power-beyond option available
• Load-holding check valve on each spool
• Levers can be rotated to multiple mounting positions
• Monoblock construction with 1–6 spool configurations available
• Each valve is individually tested for performance and leakage

TECHNICAL SPECIFICATIONS

• Type: P40 series hydraulic directional control valve
• Configuration: 4-bank double acting, closed centre (A & B ports blocked in neutral)
• Nominal flow: 40 L/min
• Maximum flow: 50 L/min
• Rated pressure: 200 bar
• Maximum pressure: 250 bar
• Relief valve setting: 180 bar (adjustable up to 250 bar max)
• Circuit type: Parallel
• Structure: High-pressure monoblock, 1–6 sections
• Spool stroke: ±5 mm
• Body material: Cast iron
• Temperature range: -15 °C to +80 °C
• Ports: P & T ports 1/2" BSPP; A & B ports 3/8" BSPP

CONTROL OPTIONS

• Standard: Manual control, spring-centered levers
• Available on request: Manual with detent, pneumatic control, hydraulic control, electro-hydraulic control
• Optional spools: Single-acting spool, motor spool
• Optional detents: Single detent, double detent
• Cable control joystick options (approx. 1–5 m lengths)
• Multi-axis joystick lever option (mounts directly to valve)

TYPICAL APPLICATIONS

• Tractors and front-end loaders
• Backhoe loaders and excavators
• Forklifts and vertical mast lifts
• Trailers and trenchers
• Wood chippers and other mobile hydraulic equipment

INSTALLATION & NOTES

• Professional installation is strongly recommended
• Please confirm the P40 specification and port sizes match your system
• Check product photos carefully to ensure compatibility with your application
• Fitment is universal for hydraulic systems; no specific vehicle list is provided

WARRANTY

• 2-year warranty against defects in materials and workmanship
