A/C Compressor CM5801 with Clutch for Ford Ranger PX & Mazda BT-50 2011-2018

PRODUCT OVERVIEW

This A/C compressor CM5801 with clutch is a direct-mount replacement designed to restore reliable air conditioning performance. Engineered to meet OE specifications, it delivers strong cooling efficiency with low noise and reduced load on the engine.

COMPATIBLE VEHICLES

• For Ford Ranger PX AWD / RWD (2011-2018)
• For Mazda BT-50 B22 / B32 AWD / RWD (2011-2018)

Note: Always confirm by part number CM5801 and specifications before ordering.

KEY FEATURES

• Strong cooling performance: Provides sufficient pressure for efficient cabin cooling.
• Low noise & low fuel consumption: Optimized load factor helps reduce power draw from the engine.
• High reliability: Built to OE-equivalent standards for stable, long-term operation.
• Complete assembly: Supplied with clutch for straightforward installation.

TECHNICAL SPECIFICATIONS

• Part number: CM5801
• Type: A/C compressor with clutch
• Mounting: Direct mount
• Material: Aluminium
• Pulley diameter: 115 mm
• Number of grooves: 7PV
• Refrigerant type: R134a
• Voltage: 12 V
• Warranty: 2 years (manufacturer terms apply)

CLUTCH & OPERATION DETAILS

• Includes coil magnet, pulley and clutch plate assembly.
• Electromagnetic clutch engages the compressor input shaft when energized.
• Freewheels on a sealed bearing when not engaged to reduce drag.

PACKAGE CONTENTS

• 1 x A/C compressor CM5801 with clutch

INSTALLATION NOTES

• Professional installation is strongly recommended.
• Verify compatibility using part number, photos and specifications before purchase.
• Replace receiver drier and flush the A/C system as required by best practice.
