A/C Compressor with Clutch for Ford Fiesta WT/WZ 1.0–1.6L 2010–2018

OVERVIEW

This replacement A/C compressor with clutch is designed for selected Ford Fiesta WT and WZ models, providing reliable cooling performance with low noise and reduced engine load.

PACKAGE CONTENTS

• 1 x A/C compressor with clutch assembly

KEY FEATURES

• Strong cooling performance with sufficient pressure for efficient cabin temperature control.
• Low noise operation for a more comfortable driving experience.
• Lower load factor to reduce power draw from the engine and improve efficiency.
• High and stable operating efficiency, designed for safety and reliability.
• Direct-mount design for straightforward replacement of the existing unit.

TECHNICAL DETAILS

• Type: A/C compressor
• Model: HS15
• Voltage: 12 V
• Material: Aluminium
• Mounting: Direct mount
• Pulley diameter: 120 mm
• Number of grooves: 6PV
• Warranty: 2 years (compressor unit only)
• Replaces: HALLA reference compressor (check OEM number before ordering)

COMPRESSOR & CLUTCH FUNCTION

• The compressor circulates refrigerant through the A/C system, enabling effective heat exchange and cooling.
• The clutch assembly includes the coil magnet, pulley and clutch plate.
• When energized, the electromagnet pulls the clutch plate against the pulley, engaging the compressor input shaft.
• When not engaged, the pulley freewheels on a sealed bearing and the compressor shaft does not turn.

VEHICLE COMPATIBILITY

Intended for selected Ford Fiesta WT and WZ models, including 1.0L, 1.5L and 1.6L engines. This compressor is commonly used on:

• Ford Fiesta WT 1.6L 4cyl Petrol-Duratec/Duratorq (approx. 2010–2013)
• Ford Fiesta WZ 1.0L 3cyl Ecoboost (approx. 2013–2018)
• Ford Fiesta WZ 1.5L 4cyl Petrol-Duratec (approx. 2013–2018)
• Ford Fiesta WZ 1.6L 4cyl Ecoboost (approx. 2013–2017)

Fitment can vary by market and sub-model. Always confirm compatibility by matching part numbers, photos and specifications with your original compressor.

INSTALLATION NOTES

• Professional installation is strongly recommended.
• Always verify part number and connector/pulley configuration against the original unit before installation.
• Ensure the A/C system is properly evacuated, flushed if required, and charged with correct refrigerant and oil type/quantity.
• Inspect and, if necessary, replace related components such as receiver drier, expansion valve and O-rings during compressor replacement.

IMPORTANT NOTICE

• Please check all pictures, specifications and any OEM or reference numbers carefully before ordering.
• Installation instructions are not included.
• Warranty generally does not cover labour, installation or re-installation costs.
