80A Alternator for Toyota Hiace KDH, Hilux KUN16 KUN26, Prado KDJ120 12V

PRODUCT OVERVIEW

Brand new 80A 12V alternator with groove clutch pulley, designed for selected Toyota diesel applications. Installation and any upgrades must be carried out by a qualified auto electrician.

Manufactured to stringent international quality standards (ISO/TS16949) for reliability and long service life.

VEHICLE APPLICATIONS

Suitable for selected:

• Toyota Hiace KDH200R, KDH205R, KDH220R, KDH222R, KDH225R, KDH227R 2.5L RWD/4WD (2004–2007)
• Includes sub-models such as LWB, SLWB, DX LONG DIESEL TURBO, HIGH ROOF variants, COMMUTER BUS and other listed trim levels.
• Toyota Hilux KUN16R, KUN26R 3.0L RWD/4WD (2005–2015) including SR, WORKMATE, SR EXTRA CAB, SR5.
• Toyota LandCruiser Prado KDJ120R 3.0L AWD (2002–2009) including TX, GX, GXL, VX, GRANDE, STANDARD.

Check all specifications and plug/pulley details against your original alternator before purchase.

SPECIFICATIONS

• Voltage: 12V
• Output: 80A
• Plug type: RP224
• Pulley: 7PV groove clutch pulley
• Pulley diameter: 63mm
• Adjustment hole: M8 x 1.25
• Pivot hole: 10mm
• Adjustment to pivot hole: 164mm
• Pivot length: 58mm

Higher output options are available separately (130A and 150A high-output units).

WHAT'S INCLUDED

• 1 x 80A 12V alternator assembly

WARRANTY & SUPPORT

• 12 month / 20,000km warranty (whichever occurs first)
• Technical support available for pre-purchase and post-purchase enquiries

Ensure professional installation and confirm compatibility with your specific vehicle model and engine code before ordering.
