PRODUCT OVERVIEW
This aluminum coolant water pipe kit is designed as a high-strength replacement for factory plastic components in select Jaguar and Land Rover 3.0L V6 and 5.0L V8 applications. It helps improve cooling system durability and reliability by upgrading to robust aluminum construction and replacing key seals and fittings.
PACKAGE INCLUDES
- Front coolant crossover pipes (upper and lower) with seals
- Rear coolant pipe with seals and temperature sensor
- Oil cooler inlet tube with seals
- Drain plug
- Water pump inlet elbow with seals
- Coolant system bleeder screw with seal
REFERENCE PART NUMBERS
This kit is suitable as a replacement for the following reference numbers (verify against your original parts before purchase):
- LR092992, LR090630, LR075991, LR122710
- AJ814053, LR048474, C2Z28258, LR055301
- LR007314, AJ811, LR109401, LR041788
- LR087558, LR049990, AJ811340, AJ813865
- C2Z28536, AJ813917, LR030593
- LR011038, LR034624, LR028136
INSTALLATION NOTES
- Ensure the part numbers match your original components before ordering.
- Professional installation is recommended; instructions are not included.
- Compare the product photos with your existing parts to confirm compatibility.
Vehicle Compatibility
| Aluminum Coolant Water Pipe Kit For Jaguar F |
Type Land Rover LR4 3.0L V6 5.0L V8 |
| Type |
Upgraded Aluminum Coolant Water Pipe Kit |
| Warranty |
2 years |
| Material |
Aluminum |
| Placement On Vehicle |
Engine Compartment |
| Engine |
3.0L V6 5.0 V8 Supercharged Engine |
| Suitable For Jaguar F-Type 3.0L V6 |
Gas, 5.0L V8 - Gas 2014-2021 |
| Suitable For Jaguar F-Pace 5.0L V8 |
Gas 2020 |
| Suitable For Jaguar F-Pace 3.0L V6 - Gas 2017 |
2020 |
| Suitable For Jaguar Xf 3.0L V6 - Gas 2013 |
2020 |
| Suitable For Jaguar Xf 5.0L V8 - Gas 2010 |
2015 |
| Suitable For Jaguar Xe 3.0L V6 - Gas 2017 |
2019 |
| Suitable For Jaguar Xj 3.0L V6 - Gas 2013 |
2019 |
| Suitable For Jaguar Xj 5.0L V8 - Gas 2010 |
2019 |
| Suitable For Land Rover Discovery 3.0L V6 - Gas 2017 |
2020 |
| Suitable For Land Rover Lr4 3.0L V6 - Gas 2010 |
2016 |
| Suitable For Land Rover Range Rover 3.0L V6 - Gas 2014 |
2020 |
| Suitable For Land Rover Range Rover 5.0L V8 - Gas 2010 |
2020 |
| Suitable For Land Rover Range Rover Sport 3.0L V6 - Gas 2014 |
2020 |
| Suitable For Land Rover Range Rover Sport 5.0L V8 |
Gas 2020 |
| Suitable For Land Rover Range Rover Sport 5.0L V8 - Gas 2010 |
2018 |
| Suitable For Land Rover Range Rover Velar 3.0L V6 - Gas 2018 |
2020 |
| Suitable For Land Rover Range Rover Velar 5.0L V8 |
Gas 2020 |
| Make |
Model |
Year |
Submodel |
Variant |
Engine |
Notes |
| Jaguar |
F-Type |
2021 |
X152 Convertible 3.0 SCV6 |
RWD Petrol 3.0L 6cyl 250kW 306PS |
2995cc 250kW (Petrol) |
|
| Jaguar |
F-Type |
2021 |
X152 Convertible 3.0 SCV6 S |
RWD Petrol 3.0L 6cyl 280kW 306PS(AJ126) |
2995cc 280kW (Petrol) |
|
| Jaguar |
F-Type |
2021 |
X152 Convertible 3.0 SCV6 S AWD |
AWD Petrol 3.0L 6cyl 280kW 306PS(AJ126) |
2995cc 280kW (Petrol) |
|
| Jaguar |
F-Type |
2021 |
X152 Coupe 3.0 SCV6 |
RWD Petrol 3.0L 6cyl 250kW 306PS |
2995cc 250kW (Petrol) |
|
| Jaguar |
F-Type |
2021 |
X152 Coupe 3.0 SCV6 S |
RWD Petrol 3.0L 6cyl 280kW 306PS(AJ126) |
2995cc 280kW (Petrol) |
|
| Jaguar |
F-Type |
2021 |
X152 Coupe 3.0 SCV6 S AWD |
AWD Petrol 3.0L 6cyl 280kW 306PS |
2995cc 280kW (Petrol) |
|
| Jaguar |
XE |
2021 |
X760 Sedan 3.0 S |
RWD Petrol 3.0L 6cyl 280kW 306PS(AJ126) |
2995cc 280kW (Petrol) |
|
| Jaguar |
XF |
2021 |
X260 Sedan 3.0 |
RWD Petrol 3.0L 6cyl 250kW 306PS |
2995cc 250kW (Petrol) |
|
| Jaguar |
XF |
2021 |
X260 Sedan 3.0 |
RWD Petrol 3.0L 6cyl 280kW 306PS |
2995cc 280kW (Petrol) |
|
| Jaguar |
XF |
2021 |
X260 Sedan 3.0 D |
RWD Diesel 3.0L 6cyl 221kW 306DT |
2993cc 221kW (Diesel) |
|
| Jaguar |
F-Type |
2020 |
X152 Convertible 3.0 SCV6 S |
RWD Petrol 3.0L 6cyl 280kW 306PS(AJ126) |
2995cc 280kW (Petrol) |
|
| Jaguar |
F-Type |
2020 |
X152 Convertible 3.0 SCV6 S AWD |
AWD Petrol 3.0L 6cyl 280kW 306PS(AJ126) |
2995cc 280kW (Petrol) |
|
| Jaguar |
F-Type |
2020 |
X152 Coupe 3.0 SCV6 |
RWD Petrol 3.0L 6cyl 250kW 306PS |
2995cc 250kW (Petrol) |
|
| Jaguar |
F-Type |
2020 |
X152 Coupe 3.0 SCV6 S |
RWD Petrol 3.0L 6cyl 280kW 306PS(AJ126) |
2995cc 280kW (Petrol) |
|
| Jaguar |
F-Type |
2020 |
X152 Coupe 3.0 SCV6 S AWD |
AWD Petrol 3.0L 6cyl 280kW 306PS |
2995cc 280kW (Petrol) |
|
| Jaguar |
XE |
2020 |
X760 Sedan 3.0 S |
RWD Petrol 3.0L 6cyl 250kW 306PS |
2995cc 250kW (Petrol) |
|
| Jaguar |
XE |
2020 |
X760 Sedan 3.0 S |
RWD Petrol 3.0L 6cyl 280kW 306PS(AJ126) |
2995cc 280kW (Petrol) |
|
| Land Rover |
Range Rover |
2020 |
L405 SUV 3.0 P400 4x4 |
AWD Petrol 3.0L 6cyl 294kW PT306(AJ20P6) |
2996cc 294kW (Petrol) |
|
| Land Rover |
Range Rover |
2020 |
L405 SUV 3.0 P400 MHEV 4x4 |
AWD Mild Hybrid 3.0L 6cyl 294kW PT306(AJ20P6) |
2996cc 294kW (Petrol/Electric) |
|
| Land Rover |
Range Rover |
2020 |
L405 SUV 3.0 SCV6 4x4 |
AWD Petrol 3.0L 6cyl 280kW 306PS |
2995cc 280kW (Petrol) |
|
