Complete Assembled Cylinder Head for Toyota 1KZ-TE Diesel Engine

PRODUCT OVERVIEW

Complete assembled cylinder head for Toyota 1KZ-TE 3.0L diesel engines. Supplied fully built with valves and related components, ready for installation.

VEHICLE APPLICATIONS

Suitable for selected Toyota models equipped with the 1KZ-TE 3.0L diesel engine, including:

• Land Cruiser (J7) 3.0 TD (KZJ70, KZJ73, KZJ77, KZJ78) – 09/2002–07/2009
• Land Cruiser Prado (J9) 3.0 TD (KZJ90, KZJ95) – 04/1995–07/2000
• Land Cruiser Prado (J12) 3.0 D-4D (KZJ12) – 09/2002–07/2009

Engine: Toyota 1KZ-TE, 2982 ccm, 4 cylinders, approx. 85 kW / 116 HP (reference data only).

REFERENCE NUMBERS

• OE reference: 1110169175
• AMC reference: 908782, 908882

TECHNICAL DETAILS

• Engine type: 1KZ-TE, 3.0L diesel
• Valve length: 104.3 mm (inlet and exhaust)
• Design: SOHC cylinder head, assembled

PACKAGE CONTENTS

• Complete assembled cylinder head
• Pre-installed valves and components
• Accessories as shown in product images

Exact contents may vary slightly; refer to product images for what is included.

1KZ-T VS 1KZ-TE CYLINDER HEAD DIFFERENCES

This cylinder head corresponds to AMC 908782 / 908882 for 1KZ-TE engines. Valve recess differs from the 1KZ-T version (AMC 908780 / 908880):

• 1KZ-TE (908782 / 908882): intake valve recess approx. 0.20 mm; exhaust valve recess approx. 1.20 mm below face
• 1KZ-T (908780 / 908880): intake valve recess approx. 0.90 mm; exhaust valve recess approx. 1.80 mm below face

Ensure you select the correct head for your specific engine code.

FITMENT NOTE

Always confirm compatibility using your vehicle identification and engine code before ordering. Specifications such as power output and model years are for guidance and may vary by market.
