Front Left 10-Pin Power Window Lift Motor for Toyota Camry & Corolla

PRODUCT OVERVIEW

This front left electric window lift motor is a high-quality aftermarket replacement designed to restore smooth and reliable power window operation. Supplied as a single unit, it is suitable for selected Toyota models listed in the vehicle fitment section.

KEY FEATURES

• Position: Front left (front passenger side)
• Type: Electric power window lift motor
• Connector: 10-pin motor plug
• Specification: High-quality aftermarket replacement
• Condition: Brand new component
• Quantity supplied: 1 piece
• MPN / Item No.: 102343M10F
• Warranty: 1 year (part only)

VEHICLE FITMENT

Use this list as a guide only. Always compare the connector, mounting points and original part before purchase.

• Toyota Camry ACV40R 07/2006–01/2012 2AZFE 2.4L Sedan
• Toyota Camry AHV40R 01/2010–02/2012 2AZFXE 2.4L Sedan
• Toyota Camry ASV50R 12/2011–10/2017 2ARFE 2.5L Sedan
• Toyota Camry AVV50R 03/2012–10/2017 2ARFXE 2.5L Sedan
• Toyota Corolla ZRE152R 05/2007–01/2014 2ZRFE 1.8L
• Toyota Corolla ZRE152R 06/2010–01/2014 3ZRFE 2.0L
• Toyota Corolla ZRE172R 12/2013–08/2019 2ZRFE 1.8L Sedan
• Toyota Corolla ZRE182R 10/2012–08/2018 2ZRFE 1.8L
• Toyota Corolla ZWE186R 06/2016–08/2018 2ZRFXE 1.8L Hatch
• Toyota HiAce TRH/KDH 01/2005–01/2019
• Toyota Hilux TGN/KUN/GGN 02/2005–08/2015
• Toyota Kluger GSU50 12/2013–11/2019

Fitment may vary within model years. Check plug type, mounting pattern and original part number where available.

ANTI-PINCH FUNCTION SETUP

If the window regulator system uses an anti-pinch safety function, follow these guidelines after installation:

• Install the motor in the door before testing. Operating it out of the door can cause the anti-pinch function to fail.
• The motors are pre-tested and set prior to supply, but may require resetting after installation.
• Connect the motor to the one-touch window switch and pull the switch up to raise the window fully.
• If the window drops after reaching the top, perform the reset procedure below.

ANTI-PINCH RESET PROCEDURE

• Step 1: Pull the window switch briefly to move the window slightly up to the top position.
• Step 2: Hold the one-touch switch up for 3–5 seconds at the top.
• Step 3: Press the window switch briefly to move the window slightly down to the bottom.
• Step 4: Hold the one-touch switch down for 3–5 seconds at the bottom.
• Step 5: Pull the one-touch switch to raise the window to the top and check that it no longer drops.

If the window still drops after reaching the top, repeat the reset steps until the anti-pinch function is correctly set.

INSTALLATION & NOTES

• Professional installation by a qualified automotive technician is recommended.
• For repair and replacement use only.
• Product images are provided as a guide; colour or finish may vary slightly due to lighting and screen settings.
• Always match the product photos and connector type to your original part before ordering.
