Front Left 6-Pin Power Window Motor for Toyota Corolla, Kluger, Camry

PRODUCT OVERVIEW

This electric window lift motor is a high-quality aftermarket replacement designed for the front left (front passenger side) door. It features a 6-pin motor connector and is supplied as a brand new unit.

KEY FEATURES

• Application: Front left (front passenger side) door
• Operating mode: Electric power window lift motor
• Connector type: 6-pin motor plug
• Specification: High quality aftermarket replacement
• Condition: Brand new
• MPN/Item No.: 102345M5F
• Quantity supplied: 1 piece
• Warranty: 1-year manufacturer warranty (part only)

VEHICLE FITMENT

Confirm part number and connector before purchase. This motor is suitable for selected models, including:

• Toyota Corolla ZZE122R 12/2001–04/2007 1ZZFE 1.8L VIN: JTD (Japan built)
• Toyota Kluger MCU28R 11/2003–07/2007 3MZFE 3.3L SUV mid-size
• Toyota Camry ACV36R 09/2002–06/2006 2AZFE 2.4L sedan
• Toyota RAV4 ACA20R 07/2000–09/2003 1AZFE 2.0L 2-door compact SUV
• Toyota RAV4 ACA21R 07/2000–03/2003 1AZFE 2.0L 4-door compact SUV
• Toyota RAV4 ACA22R 10/2003–01/2006 2AZFE 2.4L 2-door compact SUV
• Toyota RAV4 ACA23R 10/2003–01/2006 2AZFE 2.4L 4-door compact SUV

Always compare the images and specifications with your original part to ensure correct fitment.

ANTI-PINCH FUNCTION SETUP

This window motor may be used with regulators that have an anti-pinch (one-touch) safety function. Incorrect testing before installation can cause the anti-pinch function to fail and require resetting.

• Do not test the motor before it is installed in the door.
• Install the motor to the regulator and connect it to the one-touch window switch.
• Operate the switch: the window should travel fully to the top.
• If the window drops after reaching the top, perform the reset procedure below.

ANTI-PINCH RESET PROCEDURE

• Step 1: Pull the window switch briefly so the window moves slightly up to the top.
• Step 2: Hold the one-touch switch in the up position for 3–5 seconds at the top.
• Step 3: Press the window switch briefly so the window moves slightly down to the bottom.
• Step 4: Hold the one-touch switch in the down position for 3–5 seconds at the bottom.
• Step 5: Pull the one-touch switch to raise the window fully to the top and check that it no longer drops.

If the window still drops after reaching the top, repeat the reset steps until the anti-pinch function is correctly set.

INSTALLATION & WARRANTY NOTES

• For reliability and warranty validity, installation by a qualified automotive mechanic is recommended.
• Product is intended as a replacement part for repair and maintenance.
• Colour and finish may vary slightly from images due to screen and lighting differences.
• Where fitted, tamper-evident seals or labels on plugs and motor housings should not be removed, as this may affect return eligibility.

Refer to your retailer’s full warranty, returns, and delivery policies for additional terms and conditions.
