AC Compressor w/ Clutch for Skoda Octavia 2.0L Diesel 2007-2014 1KD820803H

PRODUCT OVERVIEW

This replacement air conditioning compressor with clutch is engineered to meet OEM specifications for reliable cooling performance. Designed as a direct replacement for OEM part number 1KD820803H, it provides efficient refrigerant circulation and stable operation.

KEY FEATURES

• Strong cooling performance with stable pressure output
• Low noise operation for improved driving comfort
• Reduced load on engine for lower power consumption
• Pre-assembled with clutch for easier installation
• Built to match OEM fit and function

TECHNICAL SPECIFICATIONS

• OEM part number: 1KD820803H
• Compressor type / model: 7SEU16C, PXE16
• Voltage: 12 V
• Pulley grooves: 6PV
• Pulley diameter: 115 mm
• Includes: AC compressor assembly with clutch
• Warranty: 2 years (manufacturer warranty terms apply)

FUNCTION & CLUTCH DESIGN

• Compressor circulates refrigerant through the A/C system to provide cabin cooling.
• Clutch assembly consists of coil magnet, pulley and clutch plate.
• Electromagnetic clutch engages the compressor input shaft when activated.
• When not engaged, the pulley freewheels on a sealed bearing to reduce drag.

PACKAGE CONTENTS

• 1 × air conditioning compressor with clutch (1KD820803H)

FITMENT INFORMATION

This unit is listed for various Audi, Skoda and Volkswagen applications, including selected Skoda Octavia 2.0L diesel models and other vehicles using OEM part number 1KD820803H. It is also specified for certain models with engine codes such as CBAB, CBBB, CFGB, CFGC, CAWB, BWA, BWS, CAXA, CDAA, CEAA and others where this compressor type is originally fitted.

Important: Vehicle applications can vary by market and build date. Always confirm compatibility by matching the OEM part number, compressor model, pulley type and connector style on your original unit before purchase.

INSTALLATION NOTES

• Professional installation is strongly recommended.
• Compare the new compressor with the original part before fitting.
• System must be properly evacuated, charged and leak-tested.
• Replace receiver-drier and any contaminated components as required.
• Use correct refrigerant oil type and quantity per vehicle specifications.

IMPORTANT NOTICE

• Check part number and specifications carefully before ordering.
• Images are for reference; actual appearance may vary slightly.
