Front Left Window Lift Motor 2-Pin for Toyota Hilux 2005-2015

PRODUCT OVERVIEW

This electric window lift motor is a high-quality aftermarket replacement designed for the front left (passenger side) door. It restores smooth and reliable power window operation and is supplied as a brand new unit.

KEY FEATURES

• Electric window lift motor assembly
• Front left (passenger side) fitment
• 2-pin motor connector
• High-quality aftermarket construction
• Brand new part, not reconditioned
• Supplied as 1 piece
• 12-month manufacturer warranty (part only)
• MPN/Item No.: 102023M2F

VEHICLE COMPATIBILITY

• Toyota Hilux 02/2005 - 08/2015 TGN / KUN / GGN
• Toyota HiAce TRH / KDH 01/2005 - 01/2019

Compatibility information is provided as a guide only. Always compare the part number, specifications and product images with your original part before purchase.

SPECIFICATIONS

• Product: Window lift motor
• Operating mode: Electric
• Placement on vehicle: Front left (passenger side)
• Connector type: 2-pin motor
• Part specs: High-quality aftermarket
• Condition: Brand new
• MPN/Item No.: 102023M2F
• Warranty: 1 year (part only)
• Quantity supplied: 1 piece

ANTI-PINCH FUNCTION SETUP (WHERE APPLICABLE)

If the window regulator system uses an anti-pinch function, follow the reset procedure after installation. Do not power-test the motor before it is fitted in the door, or the anti-pinch calibration may be lost.

RESET PROCEDURE (SUMMARY)

• Install the motor and connect it to the one-touch window switch.
• Operate the switch to raise the window fully and check operation.
• If the glass drops after reaching the top, perform a reset:

• Step 1: Pull the switch briefly to move the window slightly up to the top.
• Step 2: Hold the switch up for 3–5 seconds at the top position.
• Step 3: Press the switch briefly to move the window slightly down to the bottom.
• Step 4: Hold the switch down for 3–5 seconds at the bottom position.
• Step 5: Pull the one-touch switch to move the window fully up and confirm it no longer drops.

If the window still drops after reaching the top, repeat the above steps until the anti-pinch function is correctly set.

INSTALLATION & NOTES

• Recommended to be installed by a qualified automotive technician.
• Compare plug type, mounting points and motor design with the original unit.
• Colour and appearance may vary slightly from photos due to lighting and screen settings.
• Part is intended as a replacement component for repair purposes.
