Front Left Power Window Regulator with Motor 2-Pin for Holden VT–VZ

PRODUCT OVERVIEW

This front left electric window regulator with integrated 2-pin motor is a high-quality aftermarket replacement, designed to restore smooth and reliable window operation.

KEY FEATURES

• Complete regulator assembly with pre-fitted electric motor (2-pin connection)
• Direct replacement for the front left (front passenger side) position
• Durable, high quality aftermarket construction
• Supplied brand new and ready for installation
• Supported by a 1-year parts warranty

SPECIFICATIONS

• Product type: Power window regulator with motor
• Operating mode: Electric
• Placement on vehicle: Front left (front passenger side)
• Motor connector: 2-pin
• Condition: Brand new
• Part quality: High quality aftermarket
• MPN / Item No.: 100636
• Quantity supplied: 1 piece
• Manufacturer warranty: 1 year (part only)

VEHICLE FITMENT

Suitable for the following applications (verify against your original part before purchase):

• Holden Commodore VT 09/1997 - 10/2000
• Holden Commodore VX / VU 10/2000 - 08/2002
• Holden Commodore VY 09/2002 - 08/2004
• Holden Commodore VZ 08/2004 - 2007
• Holden Statesman WH 06/1999 - 05/2003
• Holden Crewman VY 09/2003 - 10/2004
• Holden Crewman VZ 08/2004 - 09/2007

Images are for reference and represent the actual style of the part supplied. Please compare the photos and specifications with your existing window regulator to confirm compatibility.

ANTI-PINCH FUNCTION RESET (WHERE APPLICABLE)

If your vehicle uses an anti-pinch function with one-touch window operation, the motor may require resetting after installation.

• Do not power-test the motor before it is installed in the door.
• Install the regulator and connect it to the one-touch window switch.
• Check operation: the window should travel fully to the top when the switch is pulled up.
• If the window drops after reaching the top, perform the reset steps below.

Reset procedure:

• Step 1: Pull the window switch briefly so the window moves slightly up to the top.
• Step 2: Hold the one-touch switch up for 3–5 seconds at the top.
• Step 3: Press the window switch briefly so the window moves slightly down to the bottom.
• Step 4: Hold the one-touch switch down for 3–5 seconds at the bottom.
• Step 5: Pull the one-touch switch again to move the window up to the top and confirm it no longer drops.

If the window still drops after reaching the top, repeat the reset steps until the anti-pinch function is correctly set.

IMPORTANT NOTES

• This part is intended for repair and replacement purposes.
• Colour or finish may appear slightly different due to screen and lighting variations.
• Professional installation by a qualified automotive mechanic is strongly recommended to maintain warranty coverage.
• Do not remove any tamper-evident seals or labels on the motor or plugs, as this may affect return eligibility.
