Front Slotted & Dimpled Brake Rotors & Bendix 4WD Pads for Triton

PRODUCT OVERVIEW

Set of 2 front slotted and dimpled vented disc brake rotors with Bendix 4WD brake pads for Triton applications. Designed to improve braking performance, cooling and pad cleaning under demanding driving conditions.

Reference part numbers: DR2208SLX4WD, DB1774/4WD, DR2208SLX, ZPN-24824

KEY FEATURES

• Dimple drilled and slotted rotor faces for enhanced cooling and gas evacuation
• Dimpled (not fully cross-drilled) to reduce risk of cracking under high thermal load
• Slots help continuously clean pad surface and reduce brake fade and glazing
• Matched set with Bendix 4WD pads for consistent braking performance
• Front axle fitment for Triton ML, MN, MQ (verify specific vehicle fitment before purchase)

ROTOR SPECIFICATIONS

• Type: Vented
• Face design: Dimple drilled & slotted
• Diameter: 295 mm
• Height: 46.5 mm
• Thickness: 28 mm
• Centre hole diameter: 94 mm
• Bolt holes / studs: 6
• Position: Front

PERFORMANCE BENEFITS

• Improved cooling efficiency compared with standard solid-face rotors
• Enhanced resistance to cracking versus fully cross-drilled designs
• Reduced brake fade during repeated high-temperature stops
• Cleaner pad surface for more consistent friction and pedal feel

WARRANTY INFORMATION

• 1 year / 25,000 km* limited warranty on rotors
• 1 year / 20,000 km* limited warranty on Bendix 4WD pads
• Rotors cast in ISO 9001:2000 OEM facilities

*Whichever occurs first. Subject to correct installation and normal use.

FITMENT NOTICE

This is a vehicle-specific front brake kit. Always confirm rotor dimensions, stud pattern and part numbers against your existing components or a trusted catalog before purchase and installation.
