Pair Front CV Driveshafts for Toyota Camry ASV50R 2.5L 2AR-FE 2011–2017

PRODUCT OVERVIEW

This front CV driveshaft pair is designed for Toyota Camry ASV50R 2.5L 2AR-FE petrol models (2011–2017, non-hybrid). Supplied as left-hand and right-hand side replacement axles with OEM-style fit and performance.

PACKAGE CONTENTS

• 1 x Front CV driveshaft – left-hand (driver or passenger side as per regional spec)
• 1 x Front CV driveshaft – right-hand (driver or passenger side as per regional spec)
• New axle nuts for installation

VEHICLE COMPATIBILITY

Suitable for selected Toyota Camry ASV50R 2.5L petrol models, including Altise and other V50 sedan variants, built approximately 12/2011–10/2017.

• Engine: 2.5L 2AR-FE, 4-cylinder petrol
• Drivetrain: FWD (front-wheel drive)
• Body: V50 sedan
• Note: Will not fit hybrid models.

Always confirm compatibility by comparing tooth counts, lengths, and existing part details before purchase.

SPECIFICATIONS

• Type: CV driveshaft / axle shaft assembly
• Condition: Brand new
• Inner CV joint (shaft 1): 24 teeth
• Outer CV joint (shaft 1): 26 teeth with bolt
• Compressed length (shaft 1): 665 mm
• Inner CV joint (shaft 2): 24 teeth
• Outer CV joint (shaft 2): 26 teeth with bolt
• Compressed length (shaft 2): 685 mm
• Exact fit: No modifications required
• Warranty: 2 years (manufacturer terms apply)

FEATURES & PERFORMANCE

• OEM-style form, fit and function for direct replacement
• Strict quality control and fitment testing
• High-quality grease formulated for high temperature and high torque
• Precision-rolled splines for correct engagement with hub and transmission
• Precision-rolled threads for secure axle nut installation
• Boot clamps crimped to create a secure seal and reduce contamination risk

CV JOINT FUNCTION

Constant velocity (CV) joints allow the driveshaft to transfer power smoothly from the transmission to the front wheels. Worn or failing CV joints can cause clunking noises, particularly when turning, and should be replaced promptly to maintain driveline reliability and safety.

INSTALLATION NOTES

• Professional installation is strongly recommended.
• Always use the new axle nuts supplied with the shafts.
• Do not reuse damaged or heavily worn mounting hardware.
• Verify tooth counts and compressed lengths against your original parts before fitting.

BEFORE YOU ORDER

• Confirm your vehicle is a non-hybrid Toyota Camry ASV50R 2.5L 2AR-FE.
• Check all specifications listed to ensure correct fitment.
• Inspect the images and compare to the existing driveshafts on your vehicle.
