Front Right Power Door Lock Mechanism for Toyota Hilux 2005-2015 690300K010

PRODUCT OVERVIEW

Front right power door lock mechanism suitable for selected Toyota Hilux models from 02/2005 to 08/2015. Designed as a quality replacement component for repair of the original door locking system.

KEY FEATURES

• Placement on vehicle: Front right (driver's side)
• Type: Power door lock mechanism
• OEM reference: 690300K010
• Suitable for repair and replacement of the original lock assembly

VEHICLE COMPATIBILITY

Intended for use on Toyota Hilux TGN/KUN/GGN models produced approximately between 02/2005 and 08/2015. Always confirm compatibility by comparing the OEM reference and product images with the original part.

INSTALLATION NOTES

• Professional installation by a qualified automotive mechanic is strongly recommended.
• Match the connector, mounting points, and overall design to the original lock mechanism before installation.
• For vehicles equipped with window regulators and motors featuring anti-pinch or one-touch functions, follow the vehicle manufacturer's reset procedure after installation.

ANTI-PINCH FUNCTION RESET (WINDOW MOTORS)

If the vehicle uses a window motor with anti-pinch/one-touch function and the window drops after reaching the top, an anti-pinch reset may be required.

• Step 1: Pull the window switch briefly so the window moves slightly up to the top.
• Step 2: Hold the one-touch switch up for 3–5 seconds at the top position.
• Step 3: Press the window switch briefly so the window moves slightly down to the bottom.
• Step 4: Hold the one-touch switch down for 3–5 seconds at the bottom position.
• Step 5: Pull the one-touch switch again to move the window fully to the top.

If the window still drops after reaching the top, repeat the above steps until the function is correctly reset.

PRODUCT USE & COLOUR NOTE

• Intended for use as a replacement part for repair purposes only.
• Product colour may vary slightly from images due to screen settings and lighting.
• Images shown are of the actual style of product supplied; always compare with the original part before purchase.

IMPORTANT DISCLAIMER

This is an aftermarket replacement component. Any genuine-branded parts supplied are obtained via independent importers or local distributors and are not sourced directly from the vehicle manufacturer.

WARRANTY & RETURNS SUMMARY

• Standard parts are generally covered by a limited manufacturer warranty period.
• Warranty covers replacement of defective parts only and excludes labour, installation, and consequential loss or damage.
• Parts must be installed by a qualified automotive mechanic to maintain warranty validity.
• Items returned due to change of mind or incorrect ordering are at the buyer's return postage cost.
• Shipping and delivery fees are non-refundable.

For full warranty, returns, and delivery terms, refer to the store's detailed policies at checkout or on the dedicated policy pages.
