AN-6 to 5/16" Female EFI Quick Connect Fuel Fitting RWF-715-06-05BK

Product Overview

The AN-6 to 5/16" female EFI quick connect fitting is designed to provide a reliable, leak-resistant connection in performance and motorsport fuel systems. It offers a secure transition between AN-6 hose ends and 5/16" OEM-style EFI hard lines or fittings.

Key Features

• AN-6 to 5/16" female EFI quick connect adapter
• Full-flow internal design to minimise restriction in fuel systems
• Hardcoat anodised finish for excellent corrosion and wear resistance
• Precision-machined from high-grade 6061 T6 billet aluminium
• Suitable for high-performance, street and motorsport applications

Compatibility & Fluids

When used with an appropriate hose series, this fitting is compatible with a wide range of automotive fluids, including E85, methanol, standard pump fuels, oils and coolants. Actual pressure ratings depend on the hose series and system components used in the installation.

Construction

• Material: 6061 T6 billet aluminium
• Finish: Hardcoat anodised
• Connection 1: AN-6
• Connection 2: 5/16" female EFI quick connect

Part Number

• Part Number: RWF-715-06-05BK

Fitment Notice

No specific vehicle compatibility is provided for this fitting. Selection should be based on required hose size, line size and system design. Always verify dimensions, fluid compatibility and connection types before purchase and installation.
