Rear Brake Pads & 268mm Brake Disc Rotor Set for Holden Trax 1.8L

PRODUCT OVERVIEW

This rear brake kit includes 2 x 268mm solid disc rotors and 1 x set of rear brake pads, supplied for both left-hand (LH) and right-hand (RH) wheels. Part number: SET_HR8040_HDB1990.

DISC ROTOR FEATURES

• Direct replacement with OE-style design
• Optimised thermal conductivity for consistent braking
• Helps reduce brake judder and vibration
• Improved damping characteristics to minimise brake noise
• High resistance to distortion and thermal cracking
• Enhanced braking safety and performance
• Designed for long rotor service life
• Effective braking with reduced pedal effort
• Lower operating temperatures to reduce stress on components
• Reduced wear for extended component life

BRAKE PAD FEATURES

• Advanced ceramic friction formula
• Engineered for everyday driving conditions
• Consistent, confident pedal feel
• Low brake noise
• Low dust output to help keep wheels cleaner

DISC ROTOR SPECIFICATIONS

• Outside diameter: 268 mm
• Height: 45 mm
• Maximum thickness: 12 mm
• Minimum thickness: 10 mm
• Centre hole (hub bore): 60 mm
• Number of studs: 5
• Disc type: Solid (S)

BRAKE PAD MEASUREMENTS

• Pad length: 117 mm
• Pad height: 43 mm
• Pad thickness: 16 mm

FITMENT & SIZE CHECK

This kit is for vehicles using 268mm rear disc rotors. Some models are available with either 268mm or 292mm rear discs. VIN details may not indicate which rear brake size is fitted.

• Confirm your existing rear rotor diameter (approximately 268mm vs 292mm) before ordering.
• The kit listed here is the 268mm rear disc and pad set.

COMPATIBLE MODELS (REFERENCE)

This 268mm rear brake setup is commonly used on the following vehicles (check rotor size to confirm):

• Holden Cruze JG 1.8L 104kW CD, CDX 05/2009–03/2011
• Holden Cruze JH 1.4T 103kW hatch & sedan 03/2011–12/2016
• Holden Cruze JH 1.8L 104kW hatch, sedan & wagon 03/2011–12/2016

WARRANTY

• Supplied with 1-year parts replacement warranty (conditions apply)
• Proof of purchase is required for all warranty claims
• Return shipping and installation labour are not included
