RH Front Electric Window Regulator & Panel for VW Transporter T5 2004-2015

PRODUCT OVERVIEW

Right-hand (front right, driver side) electric window regulator with metal panel for Volkswagen Transporter T5 models from 09/2004 to 08/2015. Supplied without motor. High-quality aftermarket replacement for OEM reference 7H0837754B.

KEY FEATURES

• Direct-fit replacement for the front right (driver side) door
• Electric operating mode, compatible with one-touch window switches
• Supplied with mounting panel for easier installation
• High-quality aftermarket construction for durability and reliability
• Brand new part with 2-year warranty (excluding installation costs)
• Replaces OEM reference number: 7H0837754B

SPECIFICATIONS

• Vehicle: Volkswagen Transporter T5
• Model years: 09/2004 – 08/2015
• Position: Front right (driver side), right-hand (RH)
• Type: Window regulator with panel
• Operating mode: Electric
• Condition: Brand new
• Quantity supplied: 1 piece
• OEM reference: 7H0837754B
• Motor: Not included (WITHOUT MOTOR)

PACKAGE CONTENTS

• 1 x right-hand front electric window regulator with panel (without motor)

ANTI-PINCH FUNCTION RESET INSTRUCTIONS

Do not power or test the motor before it is fully installed in the door, otherwise the anti-pinch function may fail and require resetting.

• Motors should be installed on the regulator and connected to the one-touch window switch.
• Pull up the switch: the window should travel fully to the top. If it then drops down, reset the anti-pinch function as below.

ANTI-PINCH RESET STEPS

• Step 1: Pull the window switch briefly so the window moves slightly up to the top.
• Step 2: Hold the one-touch switch up for 3–5 seconds at the top position.
• Step 3: Press the window switch briefly so the window moves slightly down to the bottom.
• Step 4: Hold the one-touch switch down for 3–5 seconds at the bottom position.
• Step 5: Pull the one-touch switch to move the window fully up to the top.

If the window no longer drops after reaching the top, the reset is complete. If it still drops, repeat the above steps until successful.

IMPORTANT NOTES

• Professional installation is recommended.
• Warranty does not cover labour, installation, or re-installation costs.
• Always verify part number (7H0837754B) and door position before ordering.
