Right Front CV Axle Drive Shaft for Hyundai ix35 JU81F & Kia Sportage

PRODUCT OVERVIEW

Right-hand CV axle drive shaft for front-wheel-drive applications, suitable for selected Hyundai ix35 JU81F and Kia Sportage Si / Platinum / Active models. Designed as an OEM-quality replacement for smooth, reliable power transfer from transaxle to wheel.

KEY FEATURES

• Built to OEM specifications for precise fit and performance
• Heat-treated chrome steel construction for strength and durability
• High-quality neoprene dust boots with stainless steel clamps to reduce contamination
• Filled with moly grease for low-friction operation at varying angles and speeds
• Suitable for automatic and manual FWD drivetrains (right-hand side)

VEHICLE APPLICATIONS

Intended for specific Hyundai ix35 and Kia Sportage models listed below. Always confirm compatibility by checking your vehicle build date, engine code and existing axle specifications before purchase.

• Hyundai ix35 LM 10/2013–06/2015 JU81F 2.0L G4NC I4 16V DOHC VVT (sub models including Elite, Trophy, SE)
• Hyundai ix35 Active LM 10/2013–06/2015 JU81F 2.0L G4NC I4 16V DOHC VVT
• Kia Sportage Si Premium SL 02/2014–01/2016 PC81B 2.0L G4NC I4 16V DOHC VVT
• Kia Sportage Si SL 05/2014–01/2016 PB81B 2.0L G4NC I4 16V DOHC VVT
• Kia Sportage Platinum SL 02/2014–01/2016 PC81B 2.0L G4NC I4 16V DOHC VVT

This is a general guide only and may not capture all variations. If in doubt, compare spline counts, compressed length and joint types with your original shaft.

TECHNICAL SPECIFICATIONS

• Position: Front right (RH), FWD
• Length (compressed): 562 mm
• Spline count – outer/wheel side: 27T
• Spline count – inner/diff side: 26T
• Inboard joint type: Tripod
• Outboard joint type: Ball
• ABS ring teeth: 48T

WHAT'S INCLUDED

• 1 x complete right-hand CV axle drive shaft assembly

WARRANTY

• 12 month / 20,000 km warranty on CV driveshaft
• CV boots warranted for 3 months from date of purchase

Warranty applies to defects in materials and workmanship under normal operating conditions.
