Starter Motor for Holden Commodore VE 6.0L V8 L76 L77 L98 12V 10T

PRODUCT OVERVIEW

This 12V starter motor is designed for selected Holden VE V8 petrol applications, offering reliable engine cranking performance and long service life. It features a 10-tooth pinion and clockwise rotation to match the original specification.

KEY FEATURES & SPECIFICATIONS

• Voltage: 12V
• Number of teeth: 10
• Power rating: 1.4 kW
• Rotation: Clockwise
• Overall length: 225 mm
• Mounting hole diameter: 10 mm
• Mounting holes centre distance: 73 mm
• Flange diameter: 58 mm
• Nose cone length: 42 mm
• Pinion at rest: 9 mm
• Field housing diameter: 70 mm
• Pinion diameter: 28 mm
• Terminal type: Spade terminal
• Type: Starter motor replacement unit
• Warranty: 5 years (conditions apply)

Important: Please compare all photos, mounting dimensions and electrical connections with your original starter before purchase to ensure correct fitment.

VEHICLE COMPATIBILITY

This starter motor is suitable for selected Holden VE and WM/WL petrol models as listed below. Always verify against your existing unit and vehicle details.

• Holden Senator VE 6.1L LS3 petrol (approx. 2008–2014)
• Holden GTS VE 6.1L LS3 petrol (approx. 2008–2014)
• Holden Clubsport VE 6.1L LS3 petrol (approx. 2008–2014)
• Holden Statesman WM 3.6L LLT petrol (approx. 2009–2014)
• Holden Statesman WM 6.0L L98 petrol (approx. 2006–2008)
• Holden Commodore VE 8 cyl 270 kW 6.0L L98 (GEN4) petrol (approx. 2006–2010)
• Holden Commodore VE 8 cyl Series II 270 kW 6.0L L77 (GEN3) petrol (approx. 2010–2014)
• Holden Maloo VE 6.1L LS3 petrol (approx. 2008–2014)
• Holden Grange WM 6.1L LS3 petrol (approx. 2008–2014)
• Holden Clubsport VE 6.0L LS2 (GEN4) petrol (approx. 2006–2008)
• Holden Statesman WM 6.0L L76 petrol (approx. 2008–2010)
• Holden Commodore VE 270 kW 6.0L L76 (GEN3) petrol (approx. 2008–2010)
• Holden Statesman WL 6.0L L76 petrol (2006)

Model years shown are approximate ranges derived from the supplier data. Confirm compatibility by checking engine code, build year and original part dimensions.

INSTALLATION & NOTES

• Professional installation is recommended.
• Ensure battery and charging system are in good condition before fitting.
• Clean all mounting surfaces and electrical contacts during replacement.
• Compare terminal type (spade terminal) and orientation to your original unit.

WARRANTY INFORMATION

This starter motor is supplied with a 5-year warranty against manufacturing defects. Warranty does not cover incorrect installation, misuse, or associated labour costs. Keep proof of purchase and installation records for any claim.
