Starter Motor for Suzuki Grand Vitara 3.2L N32A 4WD 08/2008–07/2012

PRODUCT OVERVIEW

This brand new starter motor is designed for Suzuki Grand Vitara 3.2L N32A 4WD models, including Prestige sub-models, produced between 08/2008 and 07/2012. Built to stringent international quality standards (ISO/TS16949), it delivers reliable starting performance and long service life.

Note: Suitable for units with spade terminal.

KEY FEATURES

• Brand new replacement starter motor (not reconditioned)
• Manufactured to ISO/TS16949 quality standards
• Optimized for reliable cold and hot starts
• Direct-fit design for specified Suzuki Grand Vitara 3.2L N32A 4WD applications
• Includes 5-year warranty for peace of mind

SPECIFICATIONS

• Voltage: 12V
• Power: 1.4kW
• Rotation direction: Clockwise
• Pinion teeth: 12
• Pinion at rest: 34
• Pinion diameter: 32mm
• Overall length: 192mm
• Mounting bolt centre–centre(s): 97–83–24
• Flange diameter: 67mm

COMPATIBILITY

• Suzuki Grand Vitara JT 3.2L N32A (08/2008–07/2012) 4WD – sub-models include Prestige
• Suzuki Grand Vitara 3.2L N32A (from 08/2008) 4WD – sub-models include JB632

Please confirm all specifications and terminal type against your original starter before purchase.

WHAT'S INCLUDED

• 1 x Starter motor for Suzuki Grand Vitara 3.2L N32A 4WD

WARRANTY

• 5-year warranty against manufacturing defects
• Warranty does not cover labour, installation or removal costs

Professional installation is recommended. Always verify vehicle details and part specifications before ordering.
