Starter Motor for Toyota HiAce TRH/RZH/RCH 2.0L 2.4L 2.7L 12V 1.6kW

PRODUCT OVERVIEW

This high-quality replacement starter motor is designed for selected Toyota HiAce TRH, RZH and RCH models. Built to stringent manufacturing standards, it delivers reliable starting performance for 2.0L, 2.4L and 2.7L petrol engines.

KEY FEATURES

• Brand new starter motor with nose cone assembly
• Manufactured to strict international quality standards
• Direct-fit replacement for compatible Toyota HiAce applications
• Engineered for consistent, reliable cold-start performance

COMPATIBLE VEHICLES

Suitable for selected Toyota HiAce models including (but not limited to):

• HiAce RZH / RCH 2.0L 1RZ-E and TRH200 2.0L 1TR-FE RWD (08/1989 - onwards) – including Commuter Bus, DX, GL, Long Body, High Roof and related variants
• HiAce RZH106 / RZH116 / RZH125 / RCH12 / RCH22 2.4L 2RZ-E RWD (08/1989 - 02/2005) – including SBV variants
• HiAce TRH201 / TRH223 / TRH221 / TRH228 / TRH226 / TRH229 / TRH224 / TRH219 / TRH214 2.7L 2TR-FE RWD/4WD (08/2004 - onwards) – including DX Long, GL Long, Commuter, LWB, SLWB, Regius Ace, Grand Cabin and related variants

Important: There are two starter plug types used on these models. Always compare the connector and mounting details with your original unit before purchasing.

TECHNICAL SPECIFICATIONS

• Voltage: 12V
• Power: 1.6 kW
• Rotation direction: Clockwise
• Pinion teeth: 9T
• Pinion at rest: 19 mm
• Pinion diameter: 29 mm
• Overall length: 180 mm
• Mounting bolt centre-to-centre: 105 mm
• Mounting hole: M10 x 1.25
• Flange diameter: 74 mm
• Nose cone length: 52 mm

WHAT'S INCLUDED

• 1 x Starter motor with nose cone

FITMENT NOTE

Check all specifications, plug type and mounting dimensions against your existing starter before ordering to ensure correct fitment for your vehicle.
