Starter Motor for Toyota Landcruiser HJ47 HJ60 HJ61 HJ75 2H 12HT 4.0L Diesel

PRODUCT OVERVIEW

Brand new high-torque starter motor engineered for Toyota Landcruiser diesel applications. Designed to deliver reliable cold-start performance and direct-fit replacement for specified 2H and 12HT 4.0L engines.

KEY FEATURES

• Brand new unit (not remanufactured)
• 12V, 2.5 kW output for strong cranking power
• 11-tooth pinion gear, clockwise (CW) rotation
• Designed as a direct replacement for listed OEM part numbers

CROSS REFERENCE PART NUMBERS

• Denso: 0280007220
• Denso: 0280007221
• Denso: 0280007222
• Denso: 0280007231
• Toyota: 2810047070
• Toyota: 2810047071
• Toyota: 2810047080
• Toyota: 2810047081

VEHICLE APPLICATIONS

Suitable for the following Toyota Landcruiser models and engines (where fitted with the listed OEM part numbers):

• Landcruiser HJ47, 2H 4.0L diesel, approx. 1980–1984
• Landcruiser HJ60, 2H 4.0L diesel, approx. 1980–1990
• Landcruiser HJ61, 12HT 4.0L turbo diesel, approx. 1987–1990
• Landcruiser HJ75, 2H 4.0L diesel, approx. 1985–1990

Body styles and configurations covered where equipped with the above engines include selected 2D Utility, 2D Hard Top, 3D Troop Carrier and 4D Wagon variants.

DIMENSIONS (MM)

• Overall length: 298 mm
• Mounting hole diameter: 13 mm
• Mount hole centre-to-centre: 140 mm
• Flange diameter: 105 mm
• Pinion diameter: 40 mm
• Out-of-mesh clearance: 17 mm

NOTES

• Compare mounting dimensions and tooth count with your original starter before purchase.
• Professional installation is recommended to ensure correct fitment and performance.
