Tailgate Rear Window Regulator & Motor 6 Pin for Land Rover Freelander

PRODUCT OVERVIEW

Electric tailgate rear window regulator with 6-pin motor, designed as a high quality aftermarket replacement for specified Land Rover Freelander applications. Supplied as a complete assembly for repair of the tailgate glass lift function.

KEY FEATURES

• Complete tailgate window regulator with integrated electric motor
• 6-pin motor connection for correct electrical interface
• Direct-fit aftermarket replacement for OE reference CVH101150
• Engineered for smooth, reliable window operation
• Supplied as 1 piece, brand new component

SPECIFICATIONS

• Product: Window regulator
• Operating mode: Electric
• Placement on vehicle: Tailgate (rear)
• Motor connector: 6 pins
• OE reference number: CVH101150
• MPN/Item No.: 100744M6D
• Condition: Brand new
• Part type: High quality aftermarket
• Quantity supplied: 1 piece
• Warranty: 1 year (part only)

VEHICLE FITMENT

• Land Rover Freelander L314 02/1998 – 04/2007 (tailgate window)

Fitment information is provided as a guide only. Always compare the part number and images with the original component before purchasing.

ANTI-PINCH FUNCTION & RESET

This motor may be equipped with an anti-pinch safety function. Do not power-test the motor before installation, as this can affect the anti-pinch calibration.

• Install the regulator and motor to the tailgate and connect to the one-touch window switch.
• Operate the switch to raise the window fully. If the glass drops after reaching the top, the anti-pinch function must be reset.

Reset procedure:

• Step 1: Pull the window switch briefly to move the glass slightly up to the top end position.
• Step 2: Hold the one-touch switch in the up position for 3–5 seconds at the top.
• Step 3: Press the window switch briefly to move the glass slightly down to the bottom end position.
• Step 4: Hold the one-touch switch in the down position for 3–5 seconds at the bottom.
• Step 5: Pull the one-touch switch to raise the window to the top again.

The reset is complete if the window remains at the top. If it drops again, repeat the steps until successful.

INSTALLATION & WARRANTY NOTES

• Professional installation by a qualified automotive technician is recommended to maintain warranty coverage.
• Warranty covers the part only and does not include labour or ancillary costs.
• For units supplied with tamper-evident seals on the plug or motor housing, removal of these seals may be treated as evidence of use and can affect return eligibility.

Product images are for the actual item supplied; minor colour variations may occur due to screen and lighting differences. Always confirm plug type, mounting points and overall layout against your original regulator before installation.
