Timing Chain Kit for Honda 2.4L K24A1 K24A2 K24A4 K24A8 2002-2011

OVERVIEW

Complete timing chain kit for select 2.4L 2354cc Honda and Acura K24 engines. Designed to restore proper timing performance and reliability with matched chains, sprockets, guides, and tensioners. Includes 2-year warranty.

VEHICLE APPLICATIONS

• Acura TSX 2.4L 2354cc L4 DOHC (16 valve), engine code K24A2, 2004-2008
• Honda Accord 2.4L 2354cc L4 DOHC (16 valve), engine code K24A4, 2003-2005
• Honda Accord 2.4L 2354cc L4 DOHC (16 valve), engine code K24A8, 2006-2007
• Honda CR-V 2.4L 2354cc L4 DOHC (16 valve), engine code K24A1, 2002-2009
• Honda Element 2.4L 2354cc L4 DOHC (16 valve), engine code K24A4, 2003-2006
• Honda Element 2.4L 2354cc L4 DOHC (16 valve), engine code K24A8, 2007-2011

Note: Cam sprocket exhaust in this kit will not fit Acura TSX K24A2 applications.

KIT CONTENTS

• 1 x Timing cam chain (176 link)
• 1 x Cam sprocket exhaust (will not fit Acura TSX K24A2)
• 1 x Crank sprocket (combo 23 teeth / 34 teeth)
• 1 x Cam chain tensioner
• 1 x Upper fixed guide rail
• 1 x Right tensioning guide rail
• 1 x Left side fixed guide rail
• 1 x Oil pump drive sprocket (17 teeth)
• 1 x Oil pump chain (62 link)
• 1 x Oil pump tensioner
• 1 x Oil pump guide rail

PART NUMBERS

Replaces or corresponds to the following reference numbers (for cross-reference only):

• 14401-R40-A01
• 14510-RAA-A01
• 14510-PNA-003
• 14511-PNA-003
• 14520-RAA-A01
• 14530-RZA-A01
• 14540-RAA-A02
• 14540-PRB-A01
• 13441-PNA-004
• 13450-RAA-A02
• 13460-PNA-004
• TS21831
• 9-0711S
• TK4041NG
• TKHO041

WARRANTY

• Warranty period: 2 years (manufacturer warranty)

INSTALLATION NOTES

• No installation instructions are included.
• Professional installation and timing alignment are strongly recommended.
• Always verify engine code and part numbers before purchase and installation.
