Toyota 1GD-FTV 2.8L D-4D Turbo Diesel Engine Specifications

OVERVIEW

The Toyota 1GD-FTV is a 2.8-liter (2755 cc) inline-four common-rail turbo diesel engine introduced in 2015. It uses a DOHC 16-valve aluminum cylinder head, variable-geometry turbocharger, intercooler, and dual-chain timing drive. Depending on calibration and market, factory power output ranges from approximately 177 to 204 horsepower (132–150 kW) with around 450–500 Nm of torque, delivering strong low-end response and efficient cruising performance.

APPLICATIONS

• Toyota Hilux (2015 onward)
• Toyota Fortuner (2015 onward)
• Toyota Land Cruiser Prado (2015–2023)
• Toyota Innova (2016–present)
• Toyota Hiace H200 (2018+)
• Toyota Dyna trucks (selected models)

KEY FEATURES

• Engine code: Toyota 1GD-FTV
• Configuration: Inline-four, DOHC, 16 valves
• Displacement: 2.8 L (2755 cc)
• Fuel system: High-pressure D-4D common-rail direct injection
• Induction: Variable-geometry turbocharger with intercooler
• Timing: Dual-chain timing system
• Power output: Approx. 177–204 hp (132–150 kW) depending on tune
• Torque: Approx. 450–500 Nm for strong towing and load capability
• Emissions control: EGR and DPF systems designed to meet Euro 5b and Euro 6 standards
• Focus on improved torque delivery, fuel efficiency, and reduced emissions while maintaining durability and reliability typical of Toyota diesel engines
