Toyota 2KD-FTV 2.5L D-4D Turbo Diesel Engine Specifications

OVERVIEW

The Toyota 2KD-FTV is a 2.5-liter (2494 cc) inline-four D-4D turbo diesel engine introduced in the early 2000s. It is designed for light to medium commercial and passenger applications, combining durability, fuel efficiency, and strong low-end torque for daily use and work environments.

ENGINE DESIGN & FEATURES

• Engine code: Toyota 2KD-FTV
• Configuration: Inline-four (4-cylinder) turbo diesel
• Displacement: 2.5 liters (2494 cc)
• Valvetrain: DOHC, 16-valve cylinder head
• Induction: Turbocharger with intercooler (later variants)
• Turbo technology: Fixed geometry on early versions, variable-geometry turbo (VGT) on later models

POWER & TORQUE OUTPUTS

• Early non-intercooled variants: approx. 75 kW (101 hp)
• Torque (early non-intercooled): approx. 260 Nm
• Later intercooled variants: up to 107 kW (143 hp)
• Torque (intercooled versions): up to 343 Nm

TYPICAL VEHICLE APPLICATIONS

The Toyota 2KD-FTV 2.5L turbo diesel engine was widely used across multiple Toyota platforms, including:

• Toyota Hilux pickup models
• Toyota Fortuner SUVs
• Toyota Dyna light trucks
• Toyota Toyoace trucks
• Hino Dutro vans and light-duty applications
• Toyota Innova MPVs
• Toyota Hiace vans

KEY CHARACTERISTICS

• Robust and simple construction for long service life
• Strong low-end torque suitable for towing and load carrying
• Known for ease of maintenance and serviceability
• Reliable performance in light to medium commercial usage

This information is provided as a general technical reference for the Toyota 2KD-FTV engine and is useful when selecting replacement engines, components, or repair kits for compatible Toyota models.
